Components

• Split case design makes it easy to remove upper casing without disturbing suction and discharge for simpler servicing and inspection.
• Dynamically balanced impeller is keyed to the shaft and secured by adjustable shaft sleeve.
• Bronze shaft sleeve extends the entire length of each stuffing box to prevent shaft wear.
• Interchangeable stuffing boxes come equipped with 303 stainless steel parts and Buna-N® elastomers for a longer pump life.
• Mechanical seals are included in standard constructions and include carbon against ceramic face for optimal hot water performance.
• Grease lubrication bearings are conveniently located for quick access and outfitted with oil seals and non-sparking neoprene rotating slingers to protect bearings during operation and washdowns.
• High-load bearings provide a minimum of 50,000 hours of performance at maximum load thanks to double-row thrust ball bearings and arms that help eliminate misalignment.
• Left-hand rotation is available with standard parts.
• Performance certification with positive suction pressure or suction lift is available on each pump for customer approval. All pumps are hydrostatically tested for optimal performance.
• Case wearing rings prevent wear on pump casing and are easy and cost-effective to replace.
