Europe - Pentair Shurflo Fresh Water Pumps

With flow reaction technology, Shurflo®' High Flow fresh water pump has a unique one-piece diaphragm and internal by-pass to assure smooth flow, long life and top performance in any plumbing system. Designed and built for high flow, low noise, smooth flow with no rapid cycling and Shurflo® reliability, this fresh water demand pump is quiet and can run dry without damage. Mounts in any position.

  • Reduced Cycling with Flow Reaction Technology™
  • Smooth, High Powered FlowRuns Dry – Thermally Protected
  • Self-Priming to 6 Vertical Feet
  • Internal Bypass-Low Cycling
  • Built-In Check Valve Prevents Back Flow
Submit an Inquiry
Contact Us

Resources

Downloads

Specifications

Name:4029
Item #AFT ModelVoltageDIMENSIONSFlow RateAmps (Max)Shut-Off Pressure
4029-281-A32K4029-281-B32K12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]520 PSI* [1.4 BAR]
4029-281-A324029-281-B3212 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]2.0 GPM [7.6 LPM]520 PSI* [1.4 BAR]
4029-281-A43KN/A12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]525 PSI* [1.7 BAR]
4029-281-A54KN/A12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]530 PSI* [2.0 BAR]
4029-281-A544029-281-B5412 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]2.0 GPM [7.6 LPM]530 PSI* [2.0 BAR]
Name:4009
Item #AFT ModelVoltageDIMENSIONSFlow RateAmps (Max)Shut-Off Pressure
4009-201-A32KN/A12 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]520 PSI* [1.4 BAR]
4009-201-A54KN/A12 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-231-A54KN/A24 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-201-A544009-201-B5412 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-231-A544009-231-B5424 VDC8.05" x 4.9" x 3.95" [205 x 125 x 100mm]3.0 GPM [11.3 LPM]530 PSI [2.0 BAR]
Show more
Name:4029
Item #AFT ModelVoltageDIMENSIONSFlow RateAmps (Max)Shut-Off Pressure
4029-281-A32K4029-281-B32K12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]520 PSI* [1.4 BAR]
4029-281-A324029-281-B3212 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]2.0 GPM [7.6 LPM]520 PSI* [1.4 BAR]
4029-281-A43KN/A12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]525 PSI* [1.7 BAR]
4029-281-A54KN/A12 VDC8.05" x 4.94" x 4.39" [205 x 125 x 111mm]2.0 GPM [7.6 LPM]530 PSI* [2.0 BAR]
4029-281-A544029-281-B5412 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]2.0 GPM [7.6 LPM]530 PSI* [2.0 BAR]
Name:4009
Item #AFT ModelVoltageDIMENSIONSFlow RateAmps (Max)Shut-Off Pressure
4009-201-A32KN/A12 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]520 PSI* [1.4 BAR]
4009-201-A54KN/A12 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-231-A54KN/A24 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-201-A544009-201-B5412 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]3.0 GPM [11.3 LPM]530 PSI* [2.0 BAR]
4009-231-A544009-231-B5424 VDC8.05" x 4.9" x 3.95" [205 x 125 x 100mm]3.0 GPM [11.3 LPM]530 PSI [2.0 BAR]
4009-231-A26N/A24 VDC8.05" x 4.9" x 3.95" [205 x 125 x 100mm]3.0 GPM [11.3 LPM]540 PSI* [2.7 BAR]
4009-201-A87KN/A12 VDC8.1" x 4.9" x 4.3" [206 x 125 x 110mm]3.0 GPM [11.3 LPM]745 PSI* [3.1 BAR]
4009-201-A874009-201-B8712 VDC8.05" x 4.94" x 4.16" [205 x 125 x 106mm]3.0 GPM [11.3 LPM]745 PSI* [3.1 BAR]
Show less

*With By-Pass
