Pentair Hypro Variable Pressure Ceramic 120˚ Spray Nozzles

Pentair Hypro Variable Pressure Ceramic spray nozzles are universal flat spray nozzles that offer a finer droplet spectrum.

  • Ideal for applications of contact pesticides
  • Fine to coarse spray droplet spectrum for high coverage applications
  • Extended pressure range
  • Low-drift within the pressure range up to 40 psi
Explore purchase options available for this product.
Where to Buy

Key Features

Variable Pressure Ceramic 120˚ Spray Nozzle

Spray pattern imaging

Spray Pattern

High-speed imaging of spray pattern produced by the Pentair Hypro Variable Pressure Ceramic spray nozzles.

Spray pattern imaging

Spray Pattern

High-speed imaging of spray pattern produced by the Pentair Hypro Variable Pressure Ceramic spray nozzles.

Previous
Next
0101

Specifications

Common Use: General
Pattern: Tapered Flat Fan
Technology: Elliptical Orifice
Material: Ceramic
Spray Angle: 120˚
Configuration: Tips, FastCap
Item #Nozzle SizeDroplet SizePressure RangeFlow Rate
Item #
VPC120-01
Nozzle Size
01
Droplet Size
F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.10-0.16 GPM (0.28-0.51 LPM)
Item #
VPC120-015
Nozzle Size
015
Droplet Size
F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.16-0.24 (0.42-0.76 LPM)
Item #
VPC120-02
Nozzle Size
02
Droplet Size
F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.21-0.32 GPM (0.56-1.03 LPM)
Item #
VPC120-025
Nozzle Size
025
Droplet Size
F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.21-0.37 GPM (0.70-1.28 LPM)
Item #
VPC120-03
Nozzle Size
03
Droplet Size
M-F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.26-0.44 GPM (0.84-1.53 LPM)
Item #
VPC120-04
Nozzle Size
04
Droplet Size
M-F
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.34-0.59 GPM) (1.12-2.04 LPM)
Item #
VPC120-05
Nozzle Size
05
Droplet Size
M
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.43-0.74 GPM (1.39-2.55 LPM)
Item #
VPC120-06
Nozzle Size
06
Droplet Size
C-M
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.51-0.88 (1.67-3.05 LPM)
Item #
VPC120-08
Nozzle Size
08
Droplet Size
C-M
Pressure Range
20-75 PSI (1.5-5 BAR)
Flow Rate
0.88-1.20 GPM (2.23-4.08 LPM)
