WhisperFlo® High Performance Pump
WhisperFlo® High Performance Pump
Proven Performance and Durability, Now DOE Compliant
Pentair is proud to announce updates to the line of WhisperFlo High Performance Pumps. We've added the first and only single-speed pump models to use NEMA Premium® Efficient motors for pool applications.* The new and improved WhisperFlo DOE compliant pumps are designed to help save electricity and optimize hydraulic horsepower without sacrificing performance.
- Available high-quality proprietary Totally Enclosed Fan-Cooled (TEFC) motor for a long, worry-free life.
- Enhanced design and balanced flow enable greater efficiency and reduced operating costs.
- Improved design that stands up to demanding installations and conditions.
- 2” NPT suction and discharge ports.
- Cam and RampTM Lid permits easy inspection and cleaning of the strainer basket.
- Available models that meet DOE minimum efficiency requirements.
Specifications
| Item # | model | Voltage | Full Load Amps | HP | SF | SFHP | Primary Listings and Certifications | Port Size (NPT) | Carton Wt. (Lbs) | Category |
|---|---|---|---|---|---|---|---|---|---|---|
| 015583 | Coming Soon | 115/208-230 | 11.7-10.3 | 2 HHP** | 13 | 2.6 | UL, NSF | 1.5 | 48 | DOE Compliant - Available in the U.S. |
| 011486 | WFDS-4 | 230 | 7.8/3.0 | 1 | 1.65 | 1.65 | UL, NSF, APSP | 2" X 2" | 47 | Available outside of the U.S. / For international use only |
| 011511 | WFE-2 | 115/208-230 | 8.8/4.5-4.4 | 1/2 | 1.90 | 0.95 | UL, NSF, APSP | 2" x 2" | 41 | Available outside of the U.S. / For international use only |
| 011512 | WFE-3 | 115/208-230 | 11.2/6.0-5.6 | 3/4 | 1.67 | 1.25 | UL, NSF | 2" X 2" | 41 | Available outside of the U.S. / For international use only |
| 011527 | WFET-4 | 115/208-230 | 15.1/8.5-7.7 | 1 | 1.65 | 1.65 | UL, NSF | 2" X 2" | 48 | Available outside of the U.S. / For international use only |
| 011528 | WFET-6 | 208-230 | 10.3-9.1 | 1-1/2 | 1.47 | 2.21 | UL, NSF | 2" X 2" | 51 | Available outside of the U.S. / For international use only |
| 011529 | WFET-8 | 208-230 | 11.7-10.3 | 2 | 1.3 | 2.6 | UL, NSF | 2" X 2" | 55 | Available outside of the U.S. / For international use only |
| 011530 | WFET-12 | 208-230 | 14.6-12.7 | 3 | 1.15 | 3.45 | UL, NSF | 2" X 2" | 59 | Available outside of the U.S. / For international use only |
| 347926 | WFEL-2 | 240/120 | 7.5/15.0 | 1/2 | 1.10 | 0.55 | 2" X 2" | 41 | Available outside of the U.S. / For international use only | |
| 347927 | WFEL-3 | 240/120 | 7.5/15.0 | 3/4 | 1.10 | 0.83 | 2" X 2" | 41 | Available outside of the U.S. / For international use only |
| Item # | model | Voltage | Full Load Amps | HP | SF | SFHP | Primary Listings and Certifications | Port Size (NPT) | Carton Wt. (Lbs) | Category |
|---|---|---|---|---|---|---|---|---|---|---|
| 015583 | Coming Soon | 115/208-230 | 11.7-10.3 | 2 HHP** | 13 | 2.6 | UL, NSF | 1.5 | 48 | DOE Compliant - Available in the U.S. |
| 011486 | WFDS-4 | 230 | 7.8/3.0 | 1 | 1.65 | 1.65 | UL, NSF, APSP | 2" X 2" | 47 | Available outside of the U.S. / For international use only |
| 011511 | WFE-2 | 115/208-230 | 8.8/4.5-4.4 | 1/2 | 1.90 | 0.95 | UL, NSF, APSP | 2" x 2" | 41 | Available outside of the U.S. / For international use only |
| 011512 | WFE-3 | 115/208-230 | 11.2/6.0-5.6 | 3/4 | 1.67 | 1.25 | UL, NSF | 2" X 2" | 41 | Available outside of the U.S. / For international use only |
| 011527 | WFET-4 | 115/208-230 | 15.1/8.5-7.7 | 1 | 1.65 | 1.65 | UL, NSF | 2" X 2" | 48 | Available outside of the U.S. / For international use only |
| 011528 | WFET-6 | 208-230 | 10.3-9.1 | 1-1/2 | 1.47 | 2.21 | UL, NSF | 2" X 2" | 51 | Available outside of the U.S. / For international use only |
| 011529 | WFET-8 | 208-230 | 11.7-10.3 | 2 | 1.3 | 2.6 | UL, NSF | 2" X 2" | 55 | Available outside of the U.S. / For international use only |
| 011530 | WFET-12 | 208-230 | 14.6-12.7 | 3 | 1.15 | 3.45 | UL, NSF | 2" X 2" | 59 | Available outside of the U.S. / For international use only |
| 347926 | WFEL-2 | 240/120 | 7.5/15.0 | 1/2 | 1.10 | 0.55 | 2" X 2" | 41 | Available outside of the U.S. / For international use only | |
| 347927 | WFEL-3 | 240/120 | 7.5/15.0 | 3/4 | 1.10 | 0.83 | 2" X 2" | 41 | Available outside of the U.S. / For international use only | |
| 347928 | WFEL-4 | 240/120 | 6.9/13.8 | 1 | 1.10 | 1.10 | 2" X 2" | 46 | Available outside of the U.S. / For international use only | |
| 347929 | WFEL-6 | 240 | 7.2 | 1.5 | 1.10 | 1.65 | 2" X 2" | 54 | Available outside of the U.S. / For international use only | |
| 347930 | WFEL-8 | 240 | 9.4 | 2 | 1.10 | 2.20 | 2" X 2" | 55 | Available outside of the U.S. / For international use only |
**Hydraulic Horse Power
1 ‘UL’ indicates that pump bears a UL mark signifying evaluation to U.S. Standards UL1081 for Permanently Connected Swimming Pool and Spa Pumps and to Canadian Standards CAN/CSA C22.2 No. 108-01 Liquid Pumps For Swimming Pools Only (Enclosure 3).
2 ‘NSF’ indicates that pump bears a mark signifying evaluation to NSF Standard 50 For Self-Priming Centrifugal Pumps For Swimming Pools, Spas and Hot Tubs.
3 'APSP' Pump has been evaluated to ANSI/APSP/ICC-15 and California Title 20 and is certified to use on Residential Swimming Pool Filtration Systems.
4 Product may have been evaluated to other state and local regulatory standards. Listing status may change. Always confirm status with appropriate agency if in doubt.
