SuperMax® High Performance Pumps
SuperMax® High Performance Pumps
A High Performance Pool Pump with DOE Compliant Options
Sta-Rite has updated the SuperMax® High Performance Pumps line by adding the first and only single speed pump to use NEMA Premium® Efficient motors for pool applications*. The new and improved SuperMax DOE compliant pumps are designed to help save electricity and optimize hydraulic horsepower without sacrificing performance.
- Available totally Enclosed Fan Cooled (TEFC) motor for maximum efficiency and durability.
- 1.5” internal slip (2” external slip) and quick-disconnect plumbing union for faster disassembly, making it a breeze to service.
- Cam and RampTM Lid permits easy inspection and cleaning of the strainer basket.
- SuperMax pumps are a high-performing drop-in replacement for the Hayward® Super Pump®**.
- Certain models meet DOE minimum efficiency requirements.
specifications
| Item # | model | Voltage | Full Load Amps | HP | SF | SFHP | Primary Listings and Certifications | Port Size (NPT) | Carton Wt. (Lbs) | Curve Key | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 348191 | Coming Soon | 115/208-230 VAC | 10.5/5.5-5.4A | 0.63 HHP*** | 1.0 | 1.1 | UL, CSA, NSF, ANSI | 1.5” | 53 | DOE Compliant - Available in the U.S. | |
| 348147 | SM N1 1FET | 115/208-230 | 15.1/8.5-7.7 | 1 | 1.65 | 1.65 | UL, NSF | 1.5" | 41 | H | Available outside of the U.S. / For international use only |
| 348148 | SM N1 1-1/2FET | 208-230 | 10.3-9.1 | 1-1/2 | 1.47 | 2.21 | UL, NSF | 1.5" | 45 | I | Available outside of the U.S. / For international use only |
| 348149 | SM N1 2FET | 208-230 | 11.7-10.3 | 2 | 1.3 | 2.6 | UL, NSF | 1.5" | 48 | J | Available outside of the U.S. / For international use only |
| 5PHK2E6C-100 | N1-1/2AE-HP | 240/120 | 7.5/15.0 | 1/2 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6D-101 | N1-3/4AE-HP | 240/120 | 7.5/15.0 | 3/4 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6E-102 | N1-1AE-HP | 240/120 | 6.9/13.8 | 1 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6F-103 | N1-1-1/2AE-HP | 240 | 7.2 | 1.5 | 1.1 | 1.5 | 52.65 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6G-104 | N1-2AE-HP | 240 | 9.4 | 2 | 1.1 | 1.5 | 52.6 | Available outside of the U.S. / For international use only | |||
| PHK2E6C-100L | N1-1/2AE-HP | 115-208-230 | 8.8/4.5-4.4 | 1/2 | 1.90 | 0.95 | UL | 1.5" | 38 | E | Available outside of the U.S. / For international use only |
| Item # | model | Voltage | Full Load Amps | HP | SF | SFHP | Primary Listings and Certifications | Port Size (NPT) | Carton Wt. (Lbs) | Curve Key | Category |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 348191 | Coming Soon | 115/208-230 VAC | 10.5/5.5-5.4A | 0.63 HHP*** | 1.0 | 1.1 | UL, CSA, NSF, ANSI | 1.5” | 53 | DOE Compliant - Available in the U.S. | |
| 348147 | SM N1 1FET | 115/208-230 | 15.1/8.5-7.7 | 1 | 1.65 | 1.65 | UL, NSF | 1.5" | 41 | H | Available outside of the U.S. / For international use only |
| 348148 | SM N1 1-1/2FET | 208-230 | 10.3-9.1 | 1-1/2 | 1.47 | 2.21 | UL, NSF | 1.5" | 45 | I | Available outside of the U.S. / For international use only |
| 348149 | SM N1 2FET | 208-230 | 11.7-10.3 | 2 | 1.3 | 2.6 | UL, NSF | 1.5" | 48 | J | Available outside of the U.S. / For international use only |
| 5PHK2E6C-100 | N1-1/2AE-HP | 240/120 | 7.5/15.0 | 1/2 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6D-101 | N1-3/4AE-HP | 240/120 | 7.5/15.0 | 3/4 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6E-102 | N1-1AE-HP | 240/120 | 6.9/13.8 | 1 | 1.1 | 1.5 | 45 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6F-103 | N1-1-1/2AE-HP | 240 | 7.2 | 1.5 | 1.1 | 1.5 | 52.65 | Available outside of the U.S. / For international use only | |||
| 5PHK2E6G-104 | N1-2AE-HP | 240 | 9.4 | 2 | 1.1 | 1.5 | 52.6 | Available outside of the U.S. / For international use only | |||
| PHK2E6C-100L | N1-1/2AE-HP | 115-208-230 | 8.8/4.5-4.4 | 1/2 | 1.90 | 0.95 | UL | 1.5" | 38 | E | Available outside of the U.S. / For international use only |
| PHK2E6D-101L | N1-3/4AE-HP | 115/208-230 | 8.8/4.5-4.4 | 3/4 | 1.25 | 0.95 | UL | 1.5" | 38 | F | Available outside of the U.S. / For international use only |
