Pentair Hypro 9205C Series Centrifugal Pumps

This pedestal mount, cast iron, direct drive centrifugal pump achieves up to 180 gpm (681 lpm) and 196 psi (13.5 bar).

  • Pedestal mount, direct drive
  • Pump shaft rotation: Counter clockwise when looking at the shaft end
  • Life Guard seals are the industry standard on OEM equipment
Find out where to purchase online or in a retail location near you.
Where to Buy

Specifications

Ports: 2" NPT inlet, 1-1⁄2" NPT outlet
Housing Material: Cast Iron
WEIGHT: 47 lbs./21.4 kg
Max Fluid Temperature: 140°F/60°C
Pump Type: Centrifugal
Impeller: Nylon
Item #Drive TypeMax GPMMax LPMMax PSIMax BARSeal MaterialShaft OutputMax RPM
9205CDirect Drive18068119613.5Viton ® /ceramic standard; Life Guard silicon carbide (B) available7⁄8" (22.2 mm) solid keyed shaft4200
Item #Drive TypeMax GPMMax LPMMax PSIMax BARSeal MaterialShaft OutputMax RPM
9205CDirect Drive18068119613.5Viton ® /ceramic standard; Life Guard silicon carbide (B) available7⁄8" (22.2 mm) solid keyed shaft4200
