IntelliFlo® Variable Speed® High Performance Pool Pump


This pump is currently discontinued.
For the recommended replacement pump, please refer to the IntelliFlo3™ VSF Pool Pump.

Why Do Intelliflo Variable Speed Pumps Outsell All Other Variable Speed Pool Pumps Combined?

IntelliFlo VS Variable Speed pump is the next generation of Pentair's variable-speed pump technology. With energy savings up to 90%* versus conventional pumps, near-silent operation and advanced programming capabilities, this pump continues to deliver everything a pool owner wants and reliability no other competitor can match.

  • Control keypad can be rotated for convenient orientation on the pump or wall-mounted with Relocation Kit
  • Intuitive, easy to use menu structure for programming and monitoring
  • Interfaces perfectly with Pentair automation systems that give you the convenience of mobile device control
  • Totally enclosed fan cooled design for quiet operation and long life
  • Top-mounted field wiring compartment makes access and installation easier
  • 8-programmable speed settings and built-in timer
  • WEF 6.9 THP 3.95
  • Available only in store from Pentair dealers or retail stores
Find out where to purchase online or in a retail location near you.


  • Dramatically quieter operation - as low as 45 decibels - about 4 times quieter than most traditional-style pumps**
  • Totally enclosed fan-cooled (TEFC) design and low average operating speed makes IntelliFlo the quietest variable speed pool pump on earth
  • Fully compatible with Pentair Automation and Controls and other brands of digital pool/spa controls for managing pump, heating, lighting, spa jets and water features
  • Built in diagnostics protect the pump for longer service life
  • The IntelliFlo Variable Speed Pump is designed to maximize the convenience and efficiency provided by Pentair Automation Systems. In response to system commands, the pump delivers just the right water flow so all your equipment operates effectively and efficiently.

Dimensional Drawings


Performance Curves


Energy Star Certified

The IntelliFlo high-performance variable speed pool pump features the smartest pump technology available.This results in increased energy savings over conventional single- or two-speed pumps, up to 90%.*


Item #modelVoltageFull Load AmpskWHPSFSFHPPort Size (NPT)Carton Wt. (Lbs)Purchase Options
011028IntelliFlo VS230163.231.323.952" x 2"55Available Through Dealer
Item #modelVoltageFull Load AmpskWHPSFSFHPPort Size (NPT)Carton Wt. (Lbs)Purchase Options
011028IntelliFlo VS230163.231.323.952" x 2"55Available Through Dealer

Products beginning with EC- are exclusive to e-commerce sales. For warranty information please visit

1 ‘UL’ indicates that pump bears a UL mark signifying evaluation to U.S. Standards UL1081 for Permanently Connected Swimming Pool and Spa Pumps and to Canadian Standards CAN/CSA C22.2 No. 108-01 Liquid Pumps For Swimming Pools Only (Enclosure 3).

2 ‘NSF’ indicates that pump bears a mark signifying evaluation to NSF Standard 50 For Self-Priming Centrifugal Pumps For Swimming Pools Only.

3 'APSP' Pump has been evaluated to ANSI/APSP/ICC-15 and CaliforniaTitle 20 and is certified to use on Residential Swimming Pool Filtration Systems.

4 Product may have been evaluated to other state and local regulatory standards. Listing status may change. Always confirm status with appropriate agency if in doubt.

Note: Pump must be used with current collectors when installed on spas orhot tubs in Canada.

*Savings based on variable speed pump compared to a single-speed pump running 12 hours per day at an average of $0.16 per kWh ina 20,000 gallon pool. Actual savings may vary based on local utility rates, pool size, pump run time, pump horse power, pump rpm, plumbing size and length, pump model, service factor and other hydraulic factors.

** Compared to noise level of typical 1.5 HP single-speed pump.
