- Pentair Shurflo NSF Carbonator Close Coupled Gear Pumps
Brochures
Manuals
The Shurflo® self-priming, positive displacement, external rotary gear hot oil pumps feature cast-iron construction for high temperature use. This series of pumps is designed for hot oil or frying oil filtration up to 375° F. meeting NSF-listing requirements. Pumps are configured with motors specifically for hot oil filtration applications where oil is heated prior to pumping. The discharge pressure limitations of these pumps should not exceed 80 PSI. They provide a nearly pulseless flow in applications where non-particulate and non-abrasive fluids are pumped. Not for use with water-based fluids. AC ODP single phase motors have thermal overload protection. Complete package is easy to install, or pump heads only can be purchased for custom installations. Pumps feature steel shaft and gears with cast iron bushing support with flows of 4.4 and 5.2 GPM. Direct couple to carbonator mount, ODP single-phase motors. Wet-end parts are constructed from cast iron, steel, 303 stainless steel, Viton and silicone. Uses: Ideal for a wide range of commercial fat fryer hot oil cooking, filtering, or waste oil rendering applications. This pump can also be used in non-NSF hot oil applications with non-particulate and non-abrasive fluids compatible with pump wet-end construction component materials.
