Pentair Flotec FP4105 1/2 HP Cast Iron Jet Pump
Main Content Starts Here
Pentair Flotec FP4105 1/2 HP Cast Iron Jet Pump
New cast iron shallow well jet pump is ideal for wells with pumping levels of 25' or less. Self-priming after the pump housing is initially filled with water.
KEY FEATURES
- Reliable performance at 25' depth to water or less
- Maximum pressures of 63 PSI and maximum pumping capacities to 5.1 GPM
- Pump housing is constructed of heavy-duty cast iron and is ready to install
- 115 volt 1/2 HPFan cooled, completely enclosed motor
- 1" Suction Port and 1" Discharge Port
WARRANTY
1 year limited warranty
Specifications
Body Construction:
Stainless Steel
MAX LIFT:
25'
Suction Pipe Size:
1-1/4" NPT
DISCHARGE PIPE SIZE:
NPT
MAXIMUM WATER TEMPERATURE:
122°F (50 °C)
Item # | Horse Power | MAXIMUM CAPACITY | FLOW at 10-foot LIST and 40 PSI | MAX PRESSURE | PRESSURE SWITCH SETTING | Amps (Max) | Voltage | RECOMMENDED BREAKER |
---|---|---|---|---|---|---|---|---|
FP4105 | 3/4 | 11 GPM | 11 GPM | 52 psi | 30/50 | 7.4 amps on 230v / 14.8 amps on 115v30v / 14.8 amps on 115v | 230v / 115v, 60 Hz | 15 amp on 230v / 20 amp on 115v |
Item # | Horse Power | MAXIMUM CAPACITY | FLOW at 10-foot LIST and 40 PSI | MAX PRESSURE | PRESSURE SWITCH SETTING | Amps (Max) | Voltage | RECOMMENDED BREAKER |
---|---|---|---|---|---|---|---|---|
FP4105 | 3/4 | 11 GPM | 11 GPM | 52 psi | 30/50 | 7.4 amps on 230v / 14.8 amps on 115v30v / 14.8 amps on 115v | 230v / 115v, 60 Hz | 15 amp on 230v / 20 amp on 115v |
